Field installation procedures minimized and simplified - pre-polished ferrule with a factory-installed fiber stub, integrated alignment mechanism and index-matching gel
Available in the following versions: - 62.5-µm multimode (OM1) - 50-µm multimode (OM2) - 50-µm laser-optimized (LO) multimode (OM3/OM4) - singlemode
ST, SC, and LC simplex connectors
Termination clip and detailed installation instructions are supplied with each connector;
Designed to terminate 250-µm and 900-µm buffered fibers, 2.0-mm and 3.0-mm jacketed fibers.
Plastic body color-coding per ANSI/TIA-598-C.3
Slim-profile boots with durable flexible cable strain relief
Field installation procedures minimized and simplified - pre-polished ferrule with a factory-installed fiber stub, integrated alignment mechanism and index-matching gel
Available in the following...
AFL LC 50-µm Laser Optimized MM OM3 OM4 Fast Connector
FASTConnect are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field. Proven...
AFL LC 62.5-µm Laser Optimized MM OM1 Fast Connector 6 Pack
FASTConnect are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field...
AFL SC 50-µm Laser Optimized MM OM3 OM4 Fast Connector
FASTConnect are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field. Proven...
AFL FAST-STMM50-6 ST 62.5-µm Laser Optimized MM OM3 OM4 Fast Connector 6 Pack
FASTConnect are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing...
AFL SC 62.5-µm Laser Optimized MM OM1 Fast Connector 6 Pack
FASTConnect are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field...
