Outdoor Back Lit Stand Alone Keypad and Proximity Card Reader >2000 Users

Outdoor Back Lit Stand Alone Keypad and Proximity Card Reader 2000 Users

• Aluminum alloy construction, waterproof, fully potted, IP65
• Built-in 125KHz (EM&HID card) reader
• Anti tamper, antistatic 15KV
• The back light can be set to Normal ON, Normal OFF or Automatic mode
• Door bell function

Specifications:

• Operating voltage range: DC12-14V
• Idle input current: ≤35mA
• Users: >2000
• Max proximity card read range: EM&HID card: 3-6cm
• IC or CPU( Mifare) card: 2-6cm
• Excitation frequency: 125KHz(EM,HID) or 13.56MHz (IC,CPU) Built-in 125KHz
• Card transmit format: Wiegand 26-37
• Keypad output format: Input a 4-6 digits PIN, sends card number, each key press sends 4 bits data, or each press sends 8 bits data
• Dimension (Height×Width×Depth)：125×83×21.7mm
• Operating temperature range: -40～60° C ( EM&HID card )
• Operating humidity: 0-95%
